Product Details:
|
| Certification: | ISO:9001 | Brand: | Sollroc |
|---|---|---|---|
| Orgin Place: | HuNan,China(Mainland) | Color: | Black Or Requested |
| Delivery Time: | 15-25 Days | MOQ: | 1pc |
| Material: | Alloy Steel | Advantage: | High Efficiency |
| Product Type: | 3 Wings Step Drag Bits | Use: | R32N R32L Self Drilling Anchor |
| Packing: | Plywood Case | Name: | R32N R32L Self Drilling Grouting Anchor Bolt Set For Tunnel Drilling |
| High Light: | oil well drilling tools,water well drilling tools |
||
Product Description:
SOLLROC self-drilling anchor bolts have a wide range of application fields including:
- Reinforcement of poor rock/soil conditions in tunnels,
- Stabilization of tunnel faces
- Tunnel root piling and
- Tunnel entrances.
Self drilling anchor bolt is extensive applied in all kinds of constructions, such as railway system, metro project and infrastructure development. As an efficient anchoring method, it’s also widely applied to pre-support project, radial support project, slope stabilization, foundation support project, soil nail wall, back pull anchor rod retaining wall and other rock supporting work.
R32N Self drilling grouting bolts
1-. Anchor bolt | It has the international standard wave-shape connecting a thread and is very easy to be installed with bit, coupling and fasten a nut. It can also be cut or connected very freely. |
2-. Plate: | To bear higher stress of surrounding rock. |
3-. Nut | To transmit the stress of surrounding rock to a plate. |
4-. Coupling | It can realize the purpose of elongating to the designed depth while drilling. |
5-. Bit | It has strong ability of penetrating, so the anchor can pass through various rocks with it. |
Item | Specifications |
R32N bolt | Dia OD/ID:32/18.5 Cross dimension:396mm2 Max tensile load(KW):280kN Yield load(KN):230kN |
Cross bit all steel(EX) | R32/D51/L56 EX |
R32/D76/L80 EX | |
Cross bit with carbide(EXX) | R32/D51/L56 EXX |
R32/D76/L85 EXX | |
button bit(ESS) | R32/D51/L60 ESS |
R32/D76/L82 ESS | |
Clay bit (EW) | R32/D76/H71 EW |
bit adaptor | R32/R38*L50 |
Coupling | R32/Φ42*L160 |
Nut | R32/SW46*L45 |
Plate R32N | 200*200*8*Φ35 |
200*200*10*Φ35 |
Features:
1-. Self drilling system eliminates the requirement for a cased borehole.
2-. Installation with simultaneous drilling and grouting possible.
3-. Easy installation in all directions, also upwards.
4-. Reliable, efficient and convenient, this makes high piling output possible.
5-. Anchor bars can be cut and lengthened according to your demands. It applies to narrow space.
Quality warranty:
Our products are made of high quality steel and all spares are inspected strictly before shipping. We have quickly responses for your complaint and suggestion.
Package:
Using ply-wooden cases and pallet for exporting to protect products and avoid the damagement during transportation. Also we can customize package according to your special requests.
Production time:
Generally, Production time is 15 -25 days.
Transportation:
By air, By Express or By sea according to your requests.
