6'' High Air Pressure DTH Hammer With API 3 1/2"Reg Thread

6'' High Air Pressure DTH Hammer With API 3 1/2"Reg Thread
6'' High Air Pressure DTH Hammer With API 3 1/2"Reg Thread 6'' High Air Pressure DTH Hammer With API 3 1/2"Reg Thread 6'' High Air Pressure DTH Hammer With API 3 1/2"Reg Thread 6'' High Air Pressure DTH Hammer With API 3 1/2"Reg Thread

Large Image :  6'' High Air Pressure DTH Hammer With API 3 1/2"Reg Thread

Product Details:
Place of Origin: China
Brand Name: SOLLROC
Certification: SGS
Model Number: DHD, SD, QL, Mission, Numa, Cop
Payment & Shipping Terms:
Minimum Order Quantity: 1 piece
Price: negotiable
Packaging Details: Cartons + ply wood case (no plastic)
Delivery Time: 18 working days
Payment Terms: T/T,
Supply Ability: 10000 pieces/month

6'' High Air Pressure DTH Hammer With API 3 1/2"Reg Thread

Description
Application: Quarrying, Construction, Civil Engineering, Mining, Usage: Mining, Water Well Drilling, Geothermal Drilling
Product Name: DTH Hammer Rock Formation: Granite, Limestone, Quartz, Etc
Shank: DHD,Cop,QL,Mission,SD Advantage: Hign Abrasion Resistance
Color: Black Or As Request Rock Hardness: Granite, Limestone, Quartz, Etc
Machine Type: Drilling Tool,Drilling Equipment,Downhole Tools,Mining Machine Parts Use: Well Drilling,Ore Mining,Coal Mining,Coal/Ore Mining,quarry
High Light:

High Air Pressure DTH Hammer

,

6'' DTH Hammer

,

API 3 1/2"Reg Thread DTH Tools

6'' High Air Pressure DTH Hammer for Water Wells, Oil, Gas and Construction Drilling



Product description

DTH system offers the very same advantages to the operator which it originally attracted to the quarry business but it's presently used in several distinct programs like gold mining, earth consolidation, geo-thermal drilling, shallow oil and gas well, piling and directional. The debut of tungsten carbide for its drill bits along with the maturation of the button drill piece combined with the coming of high air pressures has meant that the DTH system could compete easily and economically with other drilling methods.



Product Advantages:

1.offer decent control within the blasting procedure that was safer and which supplied great fragmentation of the stone.

2.Holes may be drilled into increasing depths with no reduction of functionality

3.The DTH hammer is one of the fastest ways to drill hard rock.



DTH Hammer specification:


Hammers
Bit Shank Connection Thread Suitable bit Working pressure Air consumption
6" hammers DHD360
COP64
QL60
SD6
M60
API 3 1/2"Reg ¢152-¢203mm 1.0-2.5Mpa 1.0Mpa 10m3/min
1.8Mpa 20m3/min
2.4Mpa 28.5m3/min
8" hammers DHD380
COP84
QL80
SD8
API 4 1/2"Reg ¢200-¢279mm 1.0-2.5Mpa 1.0Mpa 15m3/min
1.8Mpa 26m3/min
2.4Mpa 34m3/min
10" hammers SD10
NUMA100
API 6 5/8"Reg ¢254-¢330mm 1.0-2.5Mpa 1.0Mpa 22m3/min
1.8Mpa 40m3/min
2.4Mpa 55m3/min



Face shape Features

Drop Center

For high penetration rates in soft to medium hard and fissured rock formations. Low to medium air pressures. Maximum hole deviation control.

Concave Face

The all-round application bit face special for medium hard and homogenerous rock formations. Good hole deviation control and good flushing capacity.

Convex Face

For high penetration rates in soft to medium-hard with low to medium air pressures. It is the most resistance to steel wash, and may reduce the load and wear on the gauge buttons, but poor hole deviation control.

Flat Face

This kind of face shape is suitable for very hard and abrasive rock formations in applications with high air pressures. Good penetration rates an resistance to steel wash.

Double Gauge Face

This kind of face shape is suitable for fast penetration rates in medium to hard rock formations. Designed for high air pressures and good resistance to steel wash step gauge bit.



Product application

At present, DTH drilling tool is widely used in underground mining, quarries, hydraulic and Hydro-Power Engineering, water well drilling, Mineral exploration, anchoring hole drilling, geothermal engineering, Subway excavation, another civil engineering.



DTH is one of the most efficient ways of drilling rock, using a rapid hammer action to break the rock into sizeable chips which are then evacuated from the bore hole by the air exhausted from the DTH Hammer. The technique provides fast drilling of accurately aligned, straight and clean holes in most ground conditions.

6'' High Air Pressure DTH Hammer With API 3 1/2"Reg Thread 0
