Product Details:
|
| Material: | Carburized Steel | Color: | Red Or You Wanted |
|---|---|---|---|
| Application: | Water Well Drilling,Construction,Mining,Civil Engineering Or Water Well Drilling | Air Pressure: | High Air Pressure |
| Advatage: | High Performance And Long Service Life | Type: | DTH Drill Pipe |
| Use: | Drilling | ||
| Highlight: | Length 6m DTH Drill Rods,Geological Exploration DTH Drill Rods,Friction Welding DTH Drill Tube |
||
114mm Length 6m DTH Drill Rod With Friction Welding For Geological Exploration
Product Introduce
The DTH drill pipe consist of pipe and two adapters,box and pin.We use high strength and well-resistance alloy steel,inserting of high tensile seamless pipe,and according to different drilling depth,we can offer various thickness of pipe and material for customers' requirements.
Feature
1. In-house heat treatment ensures optimum surface hardness and case depth
2. R780 Steel -high standard
3. Long Life Thread Connection
4. Reliable and wear-resistant
Specification
| pipe diameter(mm) | pipe length(mm) | wall thickness(mm) | connection thread | |
| inch | mm | |||
| 3 | 76 | 1000-9000 | 6.3; 8 |
API 2 3/8” REG 2 3/8” IF 2 7/8” IF 3 1/2” IF 3 1/2” BECO 4 1/2” BECO |
| 3 1/2 | 89 | 1000-9600 | 6.3; 8 | |
| 4 | 102 | 1000-9000 | 6.3; 8 | |
| 4 1/2 | 114 | 1500-9140 | 8; 10 | |
| 5 | 127 | 1500-9500 | 10; 12 | |
| 5 1/2 | 140 | 1500-9500 | 14; 19 | |
We can also supply DTH drill pipe from diameter 76mm to 140mm.
About us
We are able to manufacture, export and supply our clients excellent quality DTH Hammers like DTH Hammer Bits and RC Hammer. These hammers are meticulously manufactured with utmost perfection by utilizing superior quality raw materials and efficient machinery. Sturdy in construction, the provided hammers are specifically designed to suit high pressure drilling rigs. Also, the offered DTH Hammers can be purchased from us in distinct technical specifications at industry leading rates.
Delivery Time
Generally need 15-25 days
Transport Way
By air, By Sea or By Express
