114mm Diameter 3m Length Dual Wall RC Drill Pipe with 4'' Metzke Thread for Reverse Circulation Sampling Drilling

114mm Diameter 3m Length Dual Wall RC Drill Pipe with 4'' Metzke Thread for Reverse Circulation Sampling Drilling
114mm Diameter 3m Length Dual Wall RC Drill Pipe with 4'' Metzke Thread for Reverse Circulation Sampling Drilling 114mm Diameter 3m Length Dual Wall RC Drill Pipe with 4'' Metzke Thread for Reverse Circulation Sampling Drilling 114mm Diameter 3m Length Dual Wall RC Drill Pipe with 4'' Metzke Thread for Reverse Circulation Sampling Drilling 114mm Diameter 3m Length Dual Wall RC Drill Pipe with 4'' Metzke Thread for Reverse Circulation Sampling Drilling 114mm Diameter 3m Length Dual Wall RC Drill Pipe with 4'' Metzke Thread for Reverse Circulation Sampling Drilling 114mm Diameter 3m Length Dual Wall RC Drill Pipe with 4'' Metzke Thread for Reverse Circulation Sampling Drilling

Large Image :  114mm Diameter 3m Length Dual Wall RC Drill Pipe with 4'' Metzke Thread for Reverse Circulation Sampling Drilling

Product Details:
Place of Origin: Hunan, China
Brand Name: SOLLROC
Payment & Shipping Terms:
Minimum Order Quantity: 1
Price: $300
Contact Now

114mm Diameter 3m Length Dual Wall RC Drill Pipe with 4'' Metzke Thread for Reverse Circulation Sampling Drilling

Description
Diameter: 60mm,76mm,89mm,102mm,114mm,127mm,140mm Length: 3m
Net Weight: 97kg Thread Type: 4'' Metzke; 4'' Remet; 4 1/2'' Metzke; 4 1/2'' Remet
Spanner Flat: 90mm Material: Carburized Steel
Processing Type: Forging Outer Tube O.D.: 114.3mm
Outer Tube I.D.: 97.18mm Outer Tube WT: 8.56mm
Inner Tube O.D.: 60mm Inner Tube I.D.: 50mm
Inner Tube WT: 5mm Weight 3.0 M: 97kgs
Weight 6.0 M: 172kgs
Highlight:

114mm Diameter Dual Wall RC Drill Pipe

,

3m Length Reverse Circulation Drill Pipe

,

4'' Metzke Thread RC Drill Rod

114mm Dual Wall Drill Pipe Length 3m for RC Sampling Drilling
Product Overview

SOLLROC RC Dual-wall RC drill rods/Pipes supplies air to the hammer through the annulus between the inner and outer pipe and transports cutting inside the inner tube for sampling.

Key Features
  • Hardened alloy steel tool joints with heavy duty seamless drill pipe
  • High tensile wear resistant inner tubes
  • Optimized material and production management for premium quality
  • Reliable performance for continuous drilling operations
  • Trusted by RC drilling companies worldwide
114mm Diameter 3m Length Dual Wall RC Drill Pipe with 4'' Metzke Thread for Reverse Circulation Sampling Drilling 0 114mm Diameter 3m Length Dual Wall RC Drill Pipe with 4'' Metzke Thread for Reverse Circulation Sampling Drilling 1
Right elevation
114mm Diameter 3m Length Dual Wall RC Drill Pipe with 4'' Metzke Thread for Reverse Circulation Sampling Drilling 2
Left elevation
114mm Diameter 3m Length Dual Wall RC Drill Pipe with 4'' Metzke Thread for Reverse Circulation Sampling Drilling 3
Front elevation
114mm Diameter 3m Length Dual Wall RC Drill Pipe with 4'' Metzke Thread for Reverse Circulation Sampling Drilling 4
Product Specifications
Type / Thread Remet Metzke
Rod O.D. 4 1/2" 4 1/2"
Outer tube O.D. 114.3mm 114.3mm
Outer tube I.D. 97.18mm 97.18mm
Outer tube WT 97.18mm 8.56mm
Inner tube O.D. 60mm 60mm
Inner tube I.D. 50mm 50mm
Inner tube WT 5mm 5mm
Spanner Flat 100mm 100mm
Weight 3.0 m 97kgs 97kgs
Weight 6.0 m 172kgs 172kgs
Similar Products
114mm Diameter 3m Length Dual Wall RC Drill Pipe with 4'' Metzke Thread for Reverse Circulation Sampling Drilling 5 114mm Diameter 3m Length Dual Wall RC Drill Pipe with 4'' Metzke Thread for Reverse Circulation Sampling Drilling 6 114mm Diameter 3m Length Dual Wall RC Drill Pipe with 4'' Metzke Thread for Reverse Circulation Sampling Drilling 7
Frequently Asked Questions
Package:
Buddle
Shipping:
Sea, air or express

Tag:

4.5'' Remet Thread rc drill pipe,

SGS Reverse Circulation Drill Pipe,

4.5'' Matrix Thread RC Drill Rod
