Product Details:
|
| Application: | Quarrying, Construction, Civil Engineering, Mining, | Usage: | Mining, Water Well Drilling, Geothermal Drilling |
|---|---|---|---|
| Product Name: | M50 DTH Bit | Rock Formation: | Granite, Limestone, Quartz, Etc |
| Shank: | M50 | Advantage: | Hign Abrasion Resistance |
| Color: | Black Or As Request | Size: | 5" |
| Bit Diameter: | 130-156mm | Rock Hardness: | Granite, Limestone, Quartz, Etc |
| High Light: | dth hammer bits,atlas copco dth bits |
||
High Performance M50 5" DTH Drill Bits Black Color For Water Well Drilling
Product description
DTH drilling is gaining increased interest in geotechnical applications all around the world.
With advantages such as improved hole straightness and reliable performance in challenging ground conditions, this method is turning into the number one choice for many construction companies and well drillers.
Technical Parameters
5 inch DTH bit-The data is referenced by M50 concave face bit
| Bit diameter |
Flushing holes No.*Button Dia. mm |
No.*Button Dia. mm |
Weight (kg) |
||
| mm | inch | Gauge Buttons | Front Buttons | ||
| 130 | 5 1/8” | 2*Ф20 | 7*Ф16 | 7*Ф14 | 15 |
| 135 | 5 1/4” | 2*Ф20 | 7*Ф18 | 7*Ф14 | 15.5 |
| 140 | 5 1/2” | 2*Ф20 | 8*Ф16 | 8*Ф14 | 16 |
| 146 | 5 3/4” | 2*Ф20 | 8*Ф18 | 8*Ф15 | 16.5 |
| 150 | 5 7/8” | 2*Ф20 | 8*Ф18 | 8*Ф15 | 16.7 |
| 152 | 6” | 2*Ф20 | 8*Ф18 | 8*Ф15 | 16.8 |
| 156 | 6 1/8” | 2*Ф20 | 8*Ф18 | 8*Ф16 | 17 |
Advantages
1. high quality carbide ensures high quality and performance.
2. Carbide grade options for long life in challenging applications.
3. Face designs to maximize penetration rate and tool life.
4. Optimized flushing designs to aid in cuttings removal and reduce wear
Face shape Features
Concave Face
1. Capable of drilling straighter holes in medium to hard rock which is broken or less consolidated
2. Offers high penetration rate in the above stated rock conditions
3. Has excellent air flushing characteristics
4. Predominant face style for majority of drilling conditions
Flat Face
1. Have a superior performance in hard, abrasive and broken rock conditions
2.They however have a slower penetration rate in comparison to a concave face bit
Convex Face
1. This face has been designed to offer high penetration rate in soft rock such as shale, limestone etc
2.They are recognized for having excellent capability for drilling into moderately consolidated rock conditions
Product application
At present, DTH drilling tool is widely used in underground mining, quarries, hydraulic and Hydro-Power Engineering, water well drilling, Mineral exploration, anchoring hole drilling, geothermal engineering, Subway excavation, another civil engineering.
Company informaiton
Sollroc , with more 10 years of experience ,is one of the professional manufacturer and supplier of high performance rock drilling tools like: DTH hammers and bits, RC hammers and bits, DTH drill rods and top hammer drilling tools. Our tools are widely used in different drilling applications including mining, quarrying, water well drilling, geotechnical industries and etc.
