API Reg Thread 6 8 10 Inch DTH Hammer For Stone Quarrying

API Reg Thread 6 8 10 Inch DTH Hammer For Stone Quarrying
API Reg Thread 6 8 10 Inch DTH Hammer For Stone Quarrying API Reg Thread 6 8 10 Inch DTH Hammer For Stone Quarrying API Reg Thread 6 8 10 Inch DTH Hammer For Stone Quarrying API Reg Thread 6 8 10 Inch DTH Hammer For Stone Quarrying

Large Image :  API Reg Thread 6 8 10 Inch DTH Hammer For Stone Quarrying

Product Details:
Place of Origin: China
Brand Name: SOLLROC
Certification: SGS
Model Number: DHD, SD, QL, Mission, Numa, Cop
Payment & Shipping Terms:
Minimum Order Quantity: 1 piece
Price: negotiable
Packaging Details: Cartons + ply wood case (no plastic)
Delivery Time: 18 working days
Payment Terms: T/T,
Supply Ability: 10000 pieces/month

API Reg Thread 6 8 10 Inch DTH Hammer For Stone Quarrying

Description
Application: Quarrying, Construction, Civil Engineering, Mining, Usage: Mining, Water Well Drilling, Geothermal Drilling
Product Name: DTH Hammer Rock Formation: Granite, Limestone, Quartz, Etc
Shank: DHD,Cop,QL,Mission,SD Advantage: Hign Abrasion Resistance
Color: Black Or As Request Rock Hardness: Granite, Limestone, Quartz, Etc
Machine Type: Drilling Tool,Drilling Equipment,Downhole Tools,Mining Machine Parts Use: Well Drilling,Ore Mining,Coal Mining,Coal/Ore Mining,quarry
High Light:

10 Inch DTH Hammer

,

Stone Quarrying DTH Hammer

,

API Reg Thread Down The Hole Hammer

6'' 8'' 10'' High Air Pressure DTH Drill Hammer for Mining Stone Quarrying





Product description

Sollroc offers a wide range of DTH hammers suitable for a variety of drilling operations. Our Down the Hole hammers provide the most versatile and cost effective rock drilling method.

DTH hammer is a percussion system driving a piston inside hammer body with up and donw motion by compressed air and transmitting an intensive percussion energy to the bit to enable the drilling by crushing the rock. Drilling method by DTH hammer exerts high drilling performance especially for drilling hard rock and contributes for shortening work schedule. Hence, this method is widely utilized for foundation work, landslide prevention work, quarrying services, marine civil work, etc.



Product Advantages:

1.Advanced hammer designs with high power and air efficiency increases productivity
2.Tailored product offering covers all your applications and conditions
3.Easy service and maintenance designs reduces machine downtime
4.Generic and proprietary shank options give you flexibility and reliability



DTH Hammer specification:


Hammers
Bit Shank Connection Thread Suitable bit Working pressure Air consumption
6" hammers DHD360
COP64
QL60
SD6
M60
API 3 1/2"Reg ¢152-¢203mm 1.0-2.5Mpa 1.0Mpa 10m3/min
1.8Mpa 20m3/min
2.4Mpa 28.5m3/min
8" hammers DHD380
COP84
QL80
SD8
API 4 1/2"Reg ¢200-¢279mm 1.0-2.5Mpa 1.0Mpa 15m3/min
1.8Mpa 26m3/min
2.4Mpa 34m3/min
10" hammers SD10
NUMA100
API 6 5/8"Reg ¢254-¢330mm 1.0-2.5Mpa 1.0Mpa 22m3/min
1.8Mpa 40m3/min
2.4Mpa 55m3/min



Face shape Features

Drop Center

For high penetration rates in soft to medium hard and fissured rock formations. Low to medium air pressures. Maximum hole deviation control.

Concave Face

The all-round application bit face special for medium hard and homogenerous rock formations. Good hole deviation control and good flushing capacity.

Convex Face

For high penetration rates in soft to medium-hard with low to medium air pressures. It is the most resistance to steel wash, and may reduce the load and wear on the gauge buttons, but poor hole deviation control.

Flat Face

This kind of face shape is suitable for very hard and abrasive rock formations in applications with high air pressures. Good penetration rates an resistance to steel wash.

Double Gauge Face

This kind of face shape is suitable for fast penetration rates in medium to hard rock formations. Designed for high air pressures and good resistance to steel wash step gauge bit.



Product application

At present, DTH drilling tool is widely used in underground mining, quarries, hydraulic and Hydro-Power Engineering, water well drilling, Mineral exploration, anchoring hole drilling, geothermal engineering, Subway excavation, another civil engineering.



DTH is one of the most efficient ways of drilling rock, using a rapid hammer action to break the rock into sizeable chips which are then evacuated from the bore hole by the air exhausted from the DTH Hammer. The technique provides fast drilling of accurately aligned, straight and clean holes in most ground conditions.

API Reg Thread 6 8 10 Inch DTH Hammer For Stone Quarrying 0


Company informaiton

At sollroc, customer satisfaction is our top priority. Our sales team takes a proactive approach in meeting customers’ needs. We take the time to get to know you and learn about your operations so we can better assist you. We strive to meet customers’ needs by supplying the tools and equipment you need when you need them, providing product support, and following through with excellent customer service every step of the way.
