High Air Pressure 8'' QL80 Down The Hole Hammer For Blasting Drilling

High Air Pressure 8'' QL80 Down The Hole Hammer For Blasting Drilling
High Air Pressure 8'' QL80 Down The Hole Hammer For Blasting Drilling High Air Pressure 8'' QL80 Down The Hole Hammer For Blasting Drilling High Air Pressure 8'' QL80 Down The Hole Hammer For Blasting Drilling High Air Pressure 8'' QL80 Down The Hole Hammer For Blasting Drilling

Large Image :  High Air Pressure 8'' QL80 Down The Hole Hammer For Blasting Drilling

Product Details:
Place of Origin: China
Brand Name: SOLLROC
Certification: SGS
Model Number: QL80
Payment & Shipping Terms:
Minimum Order Quantity: 1 piece
Price: negotiable
Packaging Details: Cartons + ply wood case (no plastic)
Delivery Time: 18 working days
Payment Terms: T/T,
Supply Ability: 10000 pieces/month

High Air Pressure 8'' QL80 Down The Hole Hammer For Blasting Drilling

Description
Application: Quarrying, Construction, Civil Engineering, Mining, Usage: Mining, Water Well Drilling, Geothermal Drilling
Product Name: DTH Hammer Rock Formation: Granite, Limestone, Quartz, Etc
Shank: QL80 Advantage: Hign Abrasion Resistance
Color: Black Or As Request Rock Hardness: Granite, Limestone, Quartz, Etc
Machine Type: Drilling Tool,Drilling Equipment,Downhole Tools,Mining Machine Parts Use: Well Drilling,Ore Mining,Coal Mining,Coal/Ore Mining,quarry
High Light:

QL80 Down The Hole Hammer

,

Blasting Drilling Down The Hole Hammer

,

High Air Pressure 8'' DTH Hammer

High Air Pressure 8'' QL80 Down The Hole Hammer For Blasting Drilling

Product description
DTH drilling is a percussion system driving a piston inside hammer body with up and down motion by compressed air and transmitting an intensive percussion energy to the bit to enable the drilling by crushing the rock. Drilling method by DTH hammer exerts high drilling performance especially for drilling hard rock and contributes for shortening work schedule. Hence, this method is widely utilized for foundation work, landslide prevention work, quarrying services, marine civil work, etc.

Product Advantages:
1. By using the latest rock drilling theory, optimizing the inside structure and the size of the air distribution, to make the DTH Hammer obtain the optimal energy transfer and make it achieve faster drilling speed and lower air consumption.
2. For such projects as the drill bit break, retrieving very difficult, we specially designed a safe and reliable anti-shedding device for the bit.
3. The check valve can be replaced to the one with bigger ail controlling hole to provide more efficient cuttings discharge.
4. The top sub and the drive chuck have special thread, which can achieve an easier disassemble.

DTH Hammer specification:
Model: DHD380, COP84, SD8, QL80

 DHD380
COP84
SD8QL80
Length(less bit)1492mm1463mm1465mm
Weight (less bit)188.0kg192.0kg182.00kg
External diameter180mm180mm185mm
Bits shankDHD380
COP84
SD8QL80
Bits diameter200-279mm
7 7/8" - 11"

200-279mm
7 7/8" - 11"
200-279mm
7 7/8" - 11"
Connection threadAPI 4 1/2" RegAPI 4 1/2" RegAPI 4 1/2" Reg
Air pressure1.0-2.5Mpa1.0-2.5Mpa1.0-2.5Mpa


Face shape Features
Drop Center
For high penetration rates in soft to medium hard and fissured rock formations. Low to medium air pressures. Maximum hole deviation control.
Concave Face
The all-round application bit face special for medium hard and homogenerous rock formations. Good hole deviation control and good flushing capacity.
Convex Face
For high penetration rates in soft to medium-hard with low to medium air pressures. It is the most resistance to steel wash, and may reduce the load and wear on the gauge buttons, but poor hole deviation control.
Flat Face
This kind of face shape is suitable for very hard and abrasive rock formations in applications with high air pressures. Good penetration rates an resistance to steel wash.
Double Gauge Face
This kind of face shape is suitable for fast penetration rates in medium to hard rock formations. Designed for high air pressures and good resistance to steel wash step gauge bit.

Product application
At present, DTH drilling tool is widely used in underground mining, quarries, hydraulic and Hydro-Power Engineering, water well drilling, Mineral exploration, anchoring hole drilling, geothermal engineering, Subway excavation, another civil engineering.


DTH is one of the most efficient ways of drilling rock, using a rapid hammer action to break the rock into sizeable chips which are then evacuated from the bore hole by the air exhausted from the DTH Hammer. The technique provides fast drilling of accurately aligned, straight and clean holes in most ground conditions.

High Air Pressure 8'' QL80 Down The Hole Hammer For Blasting Drilling 0
