Reverse Circulation RC Drill Bit Set High Carbon Steel Material

Reverse Circulation RC Drill Bit Set High Carbon Steel Material
Reverse Circulation RC Drill Bit Set High Carbon Steel Material
Reverse Circulation RC Drill Bit Set High Carbon Steel Material Reverse Circulation RC Drill Bit Set High Carbon Steel Material

Large Image :  Reverse Circulation RC Drill Bit Set High Carbon Steel Material

Product Details:
Place of Origin: China
Brand Name: SOLLROC
Certification: SGS
Model Number: SRC531 RC bit
Payment & Shipping Terms:
Minimum Order Quantity: 1 piece
Price: negotiate
Packaging Details: Cartons + ply wood case (no plastic)
Delivery Time: 15-22 days
Payment Terms: L/C, D/A, D/P, T/T, , MoneyGram
Supply Ability: 5000pcs per month

Reverse Circulation RC Drill Bit Set High Carbon Steel Material

Description
Color: Black Or You Wanted Material: High Carbon Steel
Application: Hole Drilling In Mines, Hydrology And Water Well ,Geothermal Well Usage: Geologic Exploration,gravel Stratu
Shank: SRC531 Diameter: 95mm
Use: Well Drilling,Masonry Drilling,Metal Drilling Product Name: Drill Bit Set
Machine Type: Drilling Tool Packing: Caton Or As Your Request
High Light:

Dia 95mm RC Drill Bit

,

Carbon Steel RC Drill Bit

,

4in Reverse Circulation Drill Bit Set

95mm Reverse Circulation RC Drill Bit Set



Product Introduce:

Reverse Circulation (RC) drilling is used to collect mineral and rock samples quickly and efficiently using a large rotary drill and air compressor. Reverse Circulation (or RC) drilling is one of the most frequently used methods of drilling used across the world as it is more cost effective and efficient then other methods of drilling. When compared to RAB (Rotary Air Blast) and diamond drilling, RC drilling seems to be somewhere in the middle when it comes to cost, time, quality of samples, technique and depth.



Adavantages:

1. Direct drilling cost reductions in the range of 25% to 40%.
2. Faster completion of drill programs with quicker delivery of results.
3. Reduced man-hours at the drill with decreased exposure to potential accidents.
4. Reduced contractor activity in the mine reduces mine support burden.
5. Indirect cost reductions gained from a simplified sampling process.


Technical Parameters

RC bits Model SRC531

Diameter No. x Button diameter
mm
Button angle Flushing holes Shroud Dia
mm
Weight
(kg)
Part No.
mm inch Gauge Button Front Button
86 3 3/8 6 x 12mm 5 x 12mm 35 2 84 6.0 SRC531-86
89 3 1/2 8 x 12mm 5 x 12mm 35 2 87 6.1 SRC531-89
95 3 3/4 8 x 12mm 6 x 12mm 35 2 93 6.3 SRC531-95
102 4 8 x 12mm 6 x 12mm 35 2 100 6.5 SRC531-102



Detailed Photo:

Reverse Circulation RC Drill Bit Set High Carbon Steel Material 0

Reverse Circulation RC Drill Bit Set High Carbon Steel Material 1

Reverse Circulation RC Drill Bit Set High Carbon Steel Material 2



Delivery Way:

By Air, By express or By Sea
