SRC543 RC Reverse Circulation Hammer with 4.5inch Hammer Size 116mm External Diameter and 120-135mm Hole Range for Mining and Water Well Drilling

Large Image : SRC543 RC Reverse Circulation Hammer with 4.5inch Hammer Size 116mm External Diameter and 120-135mm Hole Range for Mining and Water Well Drilling

Product Details:

Place of Origin:	Hunan, China
Brand Name:	SOLLROC

Payment & Shipping Terms:

Minimum Order Quantity:	1
Price:	$1,500

Contact Now

SRC543 RC Reverse Circulation Hammer with 4.5inch Hammer Size 116mm External Diameter and 120-135mm Hole Range for Mining and Water Well Drilling

Description

Weight:	63.0kg	Material:	Carburized Steel
Hammer Size:	4.5inch	External Diameter:	116mm
Length:	1191mm	Hole Range:	120mm-135mm
Bit Shank:	SRE 543	Connection Thread:	3.5''/4'' Remet 4''Metzke
Working Pressure:	1.5-3.5Mpa	Impact Rate:	35Hz
Rotation Speed:	25-40r/min	Air Consumption 1.7Mpa:	12m3/min
Air Consumption 2.4Mpa:	18m3/min	Air Consumption 3.0Mpa:	26m3/min
Machine Type:	Drilling Tool
Highlight:	4.5inch RC Hammer , 116mm External Diameter Reverse Circulation Hammer , 120-135mm Hole Range DTH Hammer

SRC543 RC Reverse Circulation Hammer for Mining

Technical Specifications

Parameter	Value
Length (Without bit)	1191mm
Weight (Without bit)	63.0kg
External diameter	116mm
Bit Shank	SRE 543
Hole range	120-135
Connection thread	3.5''/4'' Remet 4''Metzke
Working Pressure	1.5-3.5Mpa
Impact rate at 2.4Mpa	35Hz
Recommended rotation speed	25-40r/min
Air consumption	1.7Mpa: 12m³/min 2.4Mpa: 18m³/min 3.0Mpa: 26m³/min

Product Description

We manufacture and supply premium quality DTH Hammers designed for high-pressure drilling rigs. Our hammers are constructed with superior raw materials and precision engineering to ensure durability and performance. Available in various technical specifications, these hammers offer excellent value for industrial drilling applications.

Key Features

Reduces overall drilling costs by up to 40% compared to conventional methods
Faster completion of drilling process with quicker results
Safe operation with reduced manpower requirements
Lower water consumption than alternative mining methods
Simple and easy to operate
Efficient sample collection with precise depth tracking for accurate mineral deposit location

Delivery Information

Standard delivery time: 15-25 days
Express delivery (when in stock): 3-5 days

Product Images
