SRC545 121mm-146mm RC Drill Bit with 119-144mm Shroud Diameter and 1 Year Warranty for Well Drilling and Mining

SRC545 121mm-146mm RC Drill Bit with 119-144mm Shroud Diameter and 1 Year Warranty for Well Drilling and Mining
SRC545 121mm-146mm RC Drill Bit with 119-144mm Shroud Diameter and 1 Year Warranty for Well Drilling and Mining SRC545 121mm-146mm RC Drill Bit with 119-144mm Shroud Diameter and 1 Year Warranty for Well Drilling and Mining SRC545 121mm-146mm RC Drill Bit with 119-144mm Shroud Diameter and 1 Year Warranty for Well Drilling and Mining SRC545 121mm-146mm RC Drill Bit with 119-144mm Shroud Diameter and 1 Year Warranty for Well Drilling and Mining SRC545 121mm-146mm RC Drill Bit with 119-144mm Shroud Diameter and 1 Year Warranty for Well Drilling and Mining SRC545 121mm-146mm RC Drill Bit with 119-144mm Shroud Diameter and 1 Year Warranty for Well Drilling and Mining

Large Image :  SRC545 121mm-146mm RC Drill Bit with 119-144mm Shroud Diameter and 1 Year Warranty for Well Drilling and Mining

Product Details:
Place of Origin: Hunan, China
Brand Name: SOLLROC
Payment & Shipping Terms:
Minimum Order Quantity: 1
Price: $200
Contact Now

SRC545 121mm-146mm RC Drill Bit with 119-144mm Shroud Diameter and 1 Year Warranty for Well Drilling and Mining

Description
Weight: 12 KG Material: Carburized Steel
Processing Type: Forging Diameter: 121mm-146mm
Shroud Diameter: 119-144mm Face Shape: Flat, Convex, Concave, Drop Center
Button Type: Spherical, Parabolic, Ballistic Gauge Button Diameter: 8*14mm, 8*16mm
Center Button Diameter: 6*14mm+2*14mm, 6*14mm+3*14mm, 6*16mm+3*14mm Recommended Shroud Diameter: 119-144mm
Bit Head Shape: Various Button Configuration: Customizable
Drilling Method: Dual Wall Or Dual Tube Drilling Air Flow: Down The Annulus Of The Rod
Sample Collection: Via Air Hole On The Bit Head
Highlight:

121mm-146mm RC Drill Bit

,

119-144mm Shroud Diameter RC Drill Bit

,

1 Year Warranty RC Drill Bit

SRC545 133mm RC Drill Bit for RC Exploration Ore Mining & Well Drilling
Product Overview
RC drilling refers to Dual Wall or Dual Tube Drilling. RC drilling applies two rods with inner and outer tubes. Air is blown down the annulus of the rod and enters into hammer and bit. Rock formation fragments crushed by bit are collected into the inner tube via air hole on the bit head and then returned to the ground to enter the sampling system. Its hammers and bits are widely used in underground mining, quarries, hydraulic and hydro-power engineering, water well drilling, mineral exploration, anchoring hole drilling, geothermal engineering, subway excavation, and other civil engineering applications.
Features at a Glance
  • Made of quality raw material with carburized treatment for excellent wear resistance
  • Various selection options for bit head shape, button shape, and button configuration to meet customization requirements and adapt to various rock conditions
SRC545 121mm-146mm RC Drill Bit with 119-144mm Shroud Diameter and 1 Year Warranty for Well Drilling and Mining 0
SRC545 121mm-146mm RC Drill Bit with 119-144mm Shroud Diameter and 1 Year Warranty for Well Drilling and Mining 1
SRC545 121mm-146mm RC Drill Bit with 119-144mm Shroud Diameter and 1 Year Warranty for Well Drilling and Mining 2
SRC545 121mm-146mm RC Drill Bit with 119-144mm Shroud Diameter and 1 Year Warranty for Well Drilling and Mining 3
Product Specifications
Diameter Inch No.*Button Dia (mm) Recommend Shroud Dia(mm) Weight(KG)
121mm4 3/4''Guage 8*14mm,Center 6*14mm+2*14mm11910.7
124mm4 7/8''Guage 8*14mm,Center 6*14mm+2*14mm12210.9
127mm5''Guage 8*14mm,Center 6*14mm+3*14mm12511.2
130mm5 1/8''Guage 8*14mm,Center 6*14mm+3*14mm12811.5
133mm5 1/4''Guage 8*14mm,Center 6*14mm+3*14mm13111.7
135mm5 3/8''Guage 8*16mm,Center 6*16mm+3*14mm13312
137mm5 3/4''Guage 8*16mm,Center 6*16mm+3*14mm13512.3
140mm5 1/2''Guage 8*16mm,Center 6*16mm+3*14mm13812.5
143mm5 5/8''Guage 8*16mm,Center 6*16mm+3*14mm14112.8
146mm5 3/4''Guage 8*16mm,Center 6*16mm+3*14mm14413.5
SRC545 121mm-146mm RC Drill Bit with 119-144mm Shroud Diameter and 1 Year Warranty for Well Drilling and Mining 4
SRC545 121mm-146mm RC Drill Bit with 119-144mm Shroud Diameter and 1 Year Warranty for Well Drilling and Mining 5
SRC545 121mm-146mm RC Drill Bit with 119-144mm Shroud Diameter and 1 Year Warranty for Well Drilling and Mining 6
Frequently Asked Questions
Packaging:
Plywood wooden cases and pallets are used for export to protect products and avoid damage during transportation. Custom packaging is available for special requests.
Production Time:
Standard production time is 18-22 days.
Transportation:
Available by air, express, or sea according to customer requirements.

Tag:

reverse circulation drill bits,

reverse circulation hammers,

reverse circulation drilling
